Main information:
1. Goods from the warehouse in Ukraine.
2. Aesthetics of the roof/architectural solution (no need to place bulky panels on your roof anymore).
3. The integral layer of the roof is not disturbed - and this always leads to one thing - to the degradation of the roofing layer and leakage
(the roof does not need to be drilled under the metal structure for further installation of the panel).
4. Complicated roof types can also be used for energy collection.
5. Energy independence from general power grids.
6. Compared to a conventional roof, the "payback" period is incorrect. The estimated payback period for Hantile tiles is 5-13 years. Premium class tiles.
7. Uniqueness.
8. We have a complete solution. The roof and its components - both ceramic elements and electrical equipment.
Technical information:
Manufacturer - Hanergy Holding Group Ltd.
Warranty:
- On product «Hantile» – 10 years.
- On technology CIGS - 25 years with an average output of at least 85% during the specified period.
- On ceramic tiles and additional elements – 25 years.
Installation complexity - standard rafter system, qualified roofers, qualified electricians
Certificates of quality for products (zip-file)
Sealant on roof tiles - Ethylene propylene rubber (EPDM3) with durometer hardness - 85
Roofing locks з – Polyphenylene oxide (PPO) Dielectric properties allow this polymer to be used as electrical insulation for high-voltage wires. The dimensions and shape of the products remain constant even under thermal effects up to 150 °С.
Number of diodes:
Solar tiles have - 28 pieces. per 1 ㎡
For comparison:
A traditional PV panel has a 1-2 diode per 1pieces, its S=1,67 and 2 ㎡
Expensive panels like Panasonic has4-5 diodes per S=1,67 ㎡
Effective electricity generation area per square meter of roof for the Hantile product 103 watts / ㎡.
Thermopolished glass – triplex, total thickness 10 mm. It is many times stronger than ceramic. You can dance on it, checked.
Roofing product – Hantile.
Manufacturer – Hanergy Holding Group Ltd.
Technology CIGS (second generation). - plant «Miasole» plant in California. It is part of the Hanergy Holding.
(From Wikipedia): MiaSolé is an American solar energy company selling copper indium gallium selenide (CIGS) thin-film photovoltaic products. MiaSolé's manufacturing process lays CIGS on a flexible stainless steel substrate. MiaSolé produces all layers of photovoltaic material in a continuous sputtering process.[2]
Based in Santa Clara, California, the company is focused on large-scale commercial and utility projects,[3] and was acquired by privately held Chinese clean energy company Hanergy in 2013.
